Trimble Yuma 2 Rugged Tablet Computer

Product Description

Operating temperature. . . . . . . . . . . . . . . . . . . . “30 C to 60 C, MIL-STD-810G,

Method 502.5, Procedure II & III (Low Temp. Operating)

Method 501.5, Procedure II (High Temp. Operating)

Storage temperature. . . . . . . . . . . . . . . . . . . . . “40 C to 70 C, MIL-STD-810G,

Method 502.5, Procedure I (Low Temp. Storage)

Method 501.5, Procedure I (High Temp. Storage)

Humidity. . . . . . . Cycles between “30 C and 60 C at 90% RH, MIL-STD-810G,

Method 507.5, Procedure II (Humidity Aggravated Cycle)

Water. . . . . . . . . . . . . . . . . . . Survives driving rain and water spray, any direction

Water Jet 6.3 mm dia. @ 2.5 m“3 m, 12.5 Liter/min

IEC 60529, IP65

Dust. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Protected against dust: IEC 60529,

IP65 dust chamber with under pressure

Drops. . . . . . . . . . . . . . . . . . . . . . . Survives multiple 1.22 m drops MIL-STD-810G

Method 516.6 Procedure IV, Transit Drop

Vibration. . . . . . . . . . . . . . . . . . General minimum integrity and loose cargo tests

MIL-STD-810G, Method 514.6, Procedure I Procedure II,

Category 5 (Vibration) (Vibration; Truck/Trailer-Loose Cargo

Annex C, figure 514.6C-4, Table 514.6C-I, one hour)

Altitude. . . . . . . . . . MIL-STD-810G, Method 500.5, (Altitude) Procedure I, II & III

Operational at 15,000 ft

Temperature shock. . . . . . . . . . . . . . . . . . . . . . Cycles between “30 C and 60 C

MIL-STD-810G, Method 503.5, Procedure I-C

Solar exposure. . . . . MIL-STD-810G, Method 505.5, Procedure II, Solar Exposure

Chemical exposure. . . . Resistant to mild alkaline and acid cleaning solutions fuel

hydrocarbons, alcohols and common vehicle

and factory machine lubricants

Electrical

Processor. . . . . . . . . . . . . . . . . . . 1.6 GHz Intel Atom N2600 dual-core processor

RAM memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 GB DDR3 DRAM

Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 GB or 128 GB SSD

Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1024 x 600 hybrid reflective and

transmissive with capacitive touchscreen

Battery2. . . . . . . . . . . . . . . . . . . . . . . Smart batteries with LED power indicators.

Standard battery2

. . . . . . . . . . . . . . . . . . . . . . . . . . Two 7.5 V, 3000 mAh, 22 Wh

Extended battery2

. . . . . . . . . . . . . . . . . . . . . . . . . . Two 7.5 V, 6000 mAh, 45 Wh

I/O. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 mm audio jack, USB Host (2) HDMI

docking station I/O plate, DC input power

Radios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Bluetooth 4.03; Wi-Fi b/g/n

WWAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Penta-Band GSM 3.75G cellular data

GPS

Channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 (L1 code/carrier 6 only)

Integrated real-time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RTCM v2.3, SBAS1

Update rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Hz

Protocols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NMEA-0183, UBX binary

External antenna. . . . . . . . . . . . SMA port for optional antenna (external GPS kit)

Accuracy (HRMS)3

Real-time (RTCM or SBAS1

). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2“4 m

Real-time (Enhanced GPS variant, WAAS or EGNOS). . . . . . . . . . . . . . . . . . 1“2 m

Code postprocessed4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2“4 m

Certifications

FCC, CE, UL 60950, IC (Canada), RoHS compliant. RSS 210, CSA, RSS CSA

C22.2, IEC 60950, C-Tick Mark for Australia and New Zealand
