Trimble SX10

Product Description

Light source Pulsed laser 1550 nm; Laser class 1M

Beam divergence DR mode 0.2 mrad

Laser spot size at 100 m (FWHM) 14 mm

Atmospheric correction Available through field and office softwareImaging principle 3 calibrated cameras in telescope powered by

Trimble VISION technology

Cameras total field of view 360 x 300

Live view frame rate (depending on connection) Up to 15 fps

File size of one total panorama with overview camera 15 MB  35 MBFull dome 360 x 300

(Horizontal angle x vertical angle) with 10% overlap

3 minutes, 40 images, 20 mm @ 50 m per pixel

Primary panorama Area capture 90 x 45

(Horizontal angle x vertical angle) with 10 % overlap

3 minutes, 48 images, 4.4 mm @ 50 m per pixelResolution of each camera chip 5 MP (2592 x 1944 pix)

File format of images .jpeg

Field of view max 57.5 (horizontal) x 43.0 (vertical)

Field of view min 0.65 (horizontal) x 0.5 (vertical)

Total zoom (no interpolation) 84 x

35 mm equivalent focal length 36“3000 mm

Exposure modes Auto, spot exposure

Manual exposure brightness ±5 steps

White balance modes Auto, daylight, incandescent, overcast

Temperature compensated optics Yes

Calibrated cameras YesCommunication WiFi, 2.4 Ghz Spread Spectrum, cabled (USB 2.0)

IP-rating IP55

Operating temperature range “20 C to 50 C

Security Dual layer password protection
