Leica iCON GPS 60 GNSS Smart Antenna

Request to Call Back Send Inquiry

Leica iCON GPS 60 GNSS Smart Antenna Price And Quantity

Dimensions 190 mm x 100 mm x 110 mm
Battery Type Rechargeable Li-Ion, removable
Weight 1.35 kg (including battery)
Satellite Tracking GPS, GLONASS, Galileo, BeiDou, SBAS
Display Yes
Network Support NTRIP, Leica SmartNet Compatibility
Status Indicators LED and Display screen for satellite tracking, communication, battery
Correction Input/Output RTCM 2.x, 3.x, CMR, CMR+, Leica, NMEA 0183
Mounting 5/8" thread for pole or tribrach mounting
Environmental Protection IP67 Dust and Waterproof
Antenna Technology Integrated 72 channels GNSS antenna
Product Name Leica iCON GPS 60 GNSS Smart Antenna
Rover/Base Function Configurable as Base, Rover or Network Rover
Logging Interval Selectable (1 Hz - 20 Hz)
Storage Temperature -40C to +80C
Firmware Updates Upgradeable via USB or internet
Data Logging Yes
Measurement Rate Up to 20 Hz
Battery Life Up to 24 hours
Positioning Accuracy RTK (real-time kinematic): Horizontal 8 mm + 1 ppm, Vertical 15 mm + 1 ppm
Operating Temperature -40C to +65C
Memory Internal Memory, SD Card Support
Receiver Type Smart GNSS Antenna
Communication Integrated Bluetooth, Integrated GSM/UMTS 3.5G Modem, Wi-Fi
Channels 120 Channels
